Hydrocomponents & Technologies Inc.

Tap water, 205 PSI

HCTI membrane
  • Permeate flow and salt rejection based on the following test conditions: 2000 ppm TDS, 225psi (1.55Mpa), 77 F (25 C),pH 7.5 and 15% recovery
  • Flow rates for individual elements may vary+/-15%
2.5 Inch Tap Water
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-2514TW 2.5 x 14 in. 205 150 99.5% $90.00
MEM-2521TW 2.5 x 21 in. 205 300 99.5% $100.00
MEM-2540TW 2.5 x 40 in. 205 600 99.5% $190.00
4.0 Inch Tap Water
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-4014TW 4.0 x 14 in. 205 450 99.5% $180.00
MEM-4021TW 4.0 x 21 in. 205 800 99.5% $250.00
MEM-4040TW 4.0 x 40 in. 205 2000 99.5% $350.00

Low Pressure/Extra Low Pressure, 100 and 150 PSI

HCTI membrane
  • 2.5 & 4.0 LP Permeate flow and salt rejection based on the following test conditions:1500 ppm TDS, 150psi (1.05Mpa), 77 F (25 C),pH 7.5 and 15% recovery
  • 2.5 & 4.0 XLP Permeate flow and salt rejection based on the following test conditions: 500 ppm TDS, 100psi (0.7Mpa), 77 F (25 C),pH 7.5 and 15% recovery
  • Flow rates for individual elements may vary+/-15%
2.5 Inch Low Pressure
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-2514LP 2.5 x 14 in. 150 225 99.4% $100.00
MEM-2521LP 2.5 x 21 in. 150 450 99.4% $120.00
MEM-2540LP 2.5 x 40 in. 150 700 99.4% $210.00
4.0 Inch Low Pressure
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-4014LP 4.0 x 14 in. 150 650 99.4% $180.00
MEM-4021LP 4.0 x 21 in. 150 1000 99.4% $230.00
MEM-4040LP 4.0 x 40 in. 150 2000 99.4% $350.00
MEM-4040LP2 4.0 x 40 in. 150 2600 99.4% $350.00
MEM-4040LP3 4.0 x 40 in. 150 3000 98.0% $350.00
2.5 Inch Extra Low Pressure
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-2514XLP 2.5 x 14 in. 100 250 99.0% $120.00
MEM-2521XLP 2.5 x 21 in. 100 400 99.0% $150.00
MEM-2540XLP 2.5 x 40 in. 100 850 99.0% $230.00
4.0 Inch Extra Low Pressure
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-4014XLP 4.0 x 14 in. 100 800 99.0% $200.00
MEM-4021XLP 4.0 x 21 in. 100 1200 99.0% $250.00
MEM-4040XLP 4.0 x 40 in. 100 2600 99.0% $390.00

Brackish Water (fouling resistant), 225 PSI

HCTI membrane
  • Permeate flow and salt rejection based on the following test conditions: 2000 ppm TDS, 225psi (1.6Mpa), 77 F (25 C),pH 7.5 and 15% recovery
  • Flow rates for individual elements may vary+/-15%
2.5 Inch Brackish Water
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-2514BW 2.5 x 14 in. 225 150 99.5% $120.00
MEM-2521BW 2.5 x 21 in. 225 300 99.5% $150.00
MEM-2540BW 2.5 x 40 in. 225 600 99.5% $230.00
4.0 Inch Brackish Water
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-4014BW 4.0 x 14 in. 225 450 99.5% $200.00
MEM-4021BW 4.0 x 21 in. 225 1000 99.5% $250.00
MEM-4040BW 4.0 x 40 in. 225 2000 99.5% $390.00
4.0 Inch Brackish Water 300
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-4014BW300 4.0 x 14 in. 225 400 99.5% $220.00
MEM-4021BW300 4.0 x 21 in. 225 800 99.5% $240.00
MEM-4040BW300 4.0 x 40 in. 225 2000 99.5% $350.00

Sea Water/High Flow, 800 PSI

HCTI membrane
  • Permeate flow and salt rejection based on the following test conditions: 32000 ppm TDS, 800psi (5.5Mpa), 77 F (25 C),pH 7.5 and 15% recovery
  • SW-B 93% Boron rejection seawater applications
  • Flow rates for individual elements may vary+/-15%
2.5 Inch Sea Water Membranes
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-2514SW 2.5 x 14 in. 800 150 99.7% $150.00
MEM-2521SW 2.5 x 21 in. 800 250 99.7% $160.00
MEM-2540SW 2.5 x 40 in. 800 500 99.7% $250.00
4.0 Inch Sea Water Membranes
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-4021SW 4.0 x 21 in. 800 700 99.7% $360.00
MEM-4040SW 4.0 x 40 in. 800 1500 99.7% $490.00
2.5 Inch Boron Sea Water Membranes
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-2540SWB 2.5 x 40 in. 800 400 99.75% $250.00
4.0 Inch Boron Sea Water Membranes
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-4040SWB 4.0 x 40 in. 800 1300 99.75% $490.00

Nano Filtration, 70 PSI

HCTI membrane
  • HCTI NF90 elements with 90% monovalent ion rejection and more than 99% rejection of divalent ions are useful for water softening, removing endocrine disruption chemicals from drinking water and also food processing in small size systems.
  • HCTI NE70 elements with medium monovalent ion rejection and more than 99% rejection of divalent ions are useful for water softening, pretreatment for seawater desalination and food concentration in small size systems.
  • The stated performance is initial data taken after 30 minutes of operation based on the following monovalent test conditions; 2,000 mg/L NaCl solution at 75 psig (0.5 MPa) applied pressure, 15% recovery, 77°F (25°C) and pH 6.5-7.0.
  • The stated performance is initial data taken after 30 minutes of operation based on the following divalent test conditions; 2000 mg/L MgSO4 solution at 75 psig (0.5 MPa) applied pressure, 15% recovery, 77°F (25°C) and pH 6.5-7.0.
  • All elements are vacuum sealed in a polyethylene bag containing 1.0% sodium bi-sulfite solution.
  • Flow rates for individual elements may vary+/-15%
2.5 Inch NF-70 Nano Filtration
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Rejection NaCl Rejection (MgSO4)2 Price
MEM-2514NF70 2.5 x 14 in. 70 125 65.0% 99.5% $130.00
MEM-2521NF70 2.5 x 21 in. 70 175 65.0% 99.5% $160.00
MEM-2540NF70 2.5 x 40 in. 70 350 65.0% 99.5% $260.00
2.5 Inch NF-90 Nano Filtration
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Rejection NaCl Rejection (MgSO4)2 Price
MEM-2514NF90 2.5 x 14 in. 70 150 65.0% 99.5% $130.00
MEM-2521NF90 2.5 x 21 in. 70 225 65.0% 99.5% $160.00
MEM-2540NF90 2.5 x 40 in. 70 450 65.0% 99.5% $260.00
4.0 Inch NF-70 Nano Filtration
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Rejection NaCl Rejection (MgSO4)2 Price
MEM-4014NF70 4.0 x 14 in. 70 500 65.0% 99.5% $250.00
MEM-4021NF70 4.0 x 21 in. 70 750 65.0% 99.5% $300.00
MEM-4040NF70 4.0 x 40 in. 70 1500 65.0% 99.5% $450.00
4.0 Inch NF-90 Nano Filtration
Model # Nominal Size Rate PSI Permeate Flow (GPD@77°F) Rejection NaCl Rejection (MgSO4)2 Price
MEM-4014NF90 4.0 x 14 in. 70 700 65.0% 99.5% $250.00
MEM-4021NF90 4.0 x 21 in. 70 1000 65.0% 99.5% $300.00
MEM-4040NF90 4.0 x 40 in. 70 1900 65.0% 99.5% $450.00

Ultra Filtration, 40 GPM 201Lpm

HCTI membrane
  • Oily wastewater recovery membrane removal of emulsified and free oil from machine parts, wash water, and other oil-water serparation application.
  • Flow rates for individual elements may vary+/-15%
4.0 Inch Ultra Filtration Membrane (Pan-50)
Model # Area Feed flow Price
MEM4040-PAN50-47 60ft2 (5.6m2) 40 gpm (201 Lpm) $1,500.00

Residential Unit, 50 PSI

HCTI membrane
  • 2.0 Inch Tapwater Membrnes. (Designed to fit a 2.0 inch ID housing or pressure vessel)
  • Permeate flow and salt rejection based on the following test conditions: 500 ppm TDS, 50psi (0.36Mpa), 77°F (25°C),pH 7.5 and 15% recovery
  • Flow rates for individual elements may vary+/-15%
2.0 Inch Residential
Model # Test Condition Rate PSI Permeate Flow (GPD@77°F) Salt Rejection Price
MEM-1512-35 9 50 35 98.0% $30.00
MEM-1812-50 9 50 50 98.0% $36.00
MEM-2012-75 9 50 75 98.0% $50.00
MEM-2012-100 9 50 100 98.0% $60.00
